Event on

Event on	2024-08-02 12:02, Belfort F, Magnitude 1.5

Event information in GSEformat

GSE 2.1 provisional format Filter dialog for field: GSE 2.1 provisional format Select an operator Input a value and Input a value Options for empty fields: only empty fields no empty fields include empty fields
BEGIN GSE2.1 MSG_TYPE DATA MSG_ID 2024/08/02_100608685 CHE_NDC DATA_TYPE BULLETIN GSE2.1:short Reviewed Event Bulletin (REB) of the CHE_NDC for August 02, 2024, 10:02:28.007 EVENT 2024/08/02_100228007 ST-URSANNE JU Date Time Err RMS Latitude Longitude Smaj Smin Az Depth Err Ndef Nsta Gap mdist Mdist Qual Author OrigID 2024/08/02 10:02:28.01 0.04 47.3863 7.1229 55062.3 19399.1 314 5.9 13.4 10 10 246 0.06 0.13 a i uk SED -------- Magnitude Err Nsta Author OrigID MLhc 0.3 0.3 6 SED -------- Sta Dist EvAz Phase Time TRes Azim AzRes Slow SRes Def SNR Amp Per Qual Magnitude ArrID EPAUV 0.06 198.7 P 10:02:29.780 0.0 ___ 38.1 a__ MLhc 0.2 -------- SIPAD 0.06 129.1 P 10:02:29.872 0.0 ___ 35.3 a__ MLhc 0.3 -------- BOECO 0.07 117.1 P 10:02:29.960 0.0 ___ 27.1 a__ MLhc 0.2 -------- SEPRA 0.07 104.2 P 10:02:30.012 0.0 ___ 27.7 a__ MLhc 0.2 -------- BOURR 0.07 84.3 P 10:02:29.425 -0.7 ___ a__ -------- UNDER 0.10 140.1 P 10:02:30.556 0.1 ___ 20.2 a__ MLhc 0.7 -------- DAMV3 0.11 259.0 P 10:02:28.425 -2.3 ___ a__ -------- MORON 0.13 160.7 P 10:02:31.125 -0.1 ___ 24.9 a__ MLhc 0.8 -------- DAMV2 0.14 273.9 P 10:02:27.205 -3.9 ___ a__ -------- RONF 0.45 316.1 P 10:02:19.400 -17.6 ___ a__ -------- STOP

GSE 2.1 provisional format

BEGIN GSE2.1
MSG_TYPE DATA
MSG_ID 2024/08/02_100608685 CHE_NDC
DATA_TYPE BULLETIN GSE2.1:short
Reviewed Event Bulletin (REB) of the CHE_NDC for August 02, 2024, 10:02:28.007
EVENT 2024/08/02_100228007 ST-URSANNE JU
Date Time Err RMS Latitude Longitude Smaj Smin Az Depth Err Ndef Nsta Gap mdist Mdist Qual Author OrigID
2024/08/02 10:02:28.01 0.04 47.3863 7.1229 55062.3 19399.1 314 5.9 13.4 10 10 246 0.06 0.13 a i uk SED --------

Magnitude Err Nsta Author OrigID
MLhc 0.3 0.3 6 SED --------

Sta Dist EvAz Phase Time TRes Azim AzRes Slow SRes Def SNR Amp Per Qual Magnitude ArrID
EPAUV 0.06 198.7 P 10:02:29.780 0.0 ___ 38.1 a__ MLhc 0.2 --------
SIPAD 0.06 129.1 P 10:02:29.872 0.0 ___ 35.3 a__ MLhc 0.3 --------
BOECO 0.07 117.1 P 10:02:29.960 0.0 ___ 27.1 a__ MLhc 0.2 --------
SEPRA 0.07 104.2 P 10:02:30.012 0.0 ___ 27.7 a__ MLhc 0.2 --------
BOURR 0.07 84.3 P 10:02:29.425 -0.7 ___ a__ --------
UNDER 0.10 140.1 P 10:02:30.556 0.1 ___ 20.2 a__ MLhc 0.7 --------
DAMV3 0.11 259.0 P 10:02:28.425 -2.3 ___ a__ --------
MORON 0.13 160.7 P 10:02:31.125 -0.1 ___ 24.9 a__ MLhc 0.8 --------
DAMV2 0.14 273.9 P 10:02:27.205 -3.9 ___ a__ --------
RONF 0.45 316.1 P 10:02:19.400 -17.6 ___ a__ --------

STOP

Event Information

Event information in GSEformat

Event information in QuakeML format
